A1469 Datasheet PDF — Sanyo Semiconductor Corporation

Part Number A1469
Description PNP Transistor — 2SA1469
Manufacturers Sanyo Semiconductor Corporation
Logo

There is a preview and A1469 download ( pdf file ) link at the bottom of this page.

Total 3 Pages

Preview 1 page

No Preview Available !

Ordering number:EN1973A
PNP/NPN Epitaxial Planar Silicon Transistors
2SA1469/2SC3746
60V/5A High-Speed Switching Applications
Applications
· Various inductance lamp drivers for electrical
equipment.
· Inverters, converters (strobo, flash, fluorescent lamp
lighting circuit).
· Power amp (high power car stereo, motor controller).
· High-speed switching (switching regulator, driver).
Package Dimensions
unit:mm
2041
[2SA1469/2SC3746]
Features
· Low saturation voltage.

· Excellent current dependence of hFE.

· Short switching time.
· Micaless package facilitating mounting.
( ) : 2SA1469
Specifications

Absolute Maximum Ratings at Ta = 25˚C

Parameter
Collector-to-Base Voltage
Collector-to-Emitter Voltage
Emitter-to-Base Voltage
Collector Current
Collector Current (Pulse)
Collector Dissipation
Symbol
VCBO
VCEO
VEBO
IC
ICP
PC

www.DatJauSnhcteioent4TUem.cpoemrature

Storage Temperature
Tj
Tstg

Electrical Characteristics at Ta = 25˚C

Tc=25˚C
Conditions
Parameter
Symbol
Conditions
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
Gain-Bandwidth Product
Collector-to-Emitter Saturation Voltage
Collector-to-Base Breakdown Voltage
Collector-to-Emitter Breakdown Voltage
Emitter-to-Base Breakdown Votage
Turn-ON Time
Storage Time
Fall Time
ICBO
IEBO
hFE
fT
VCE(sat)
V(BR)CBO
V(BR)CEO
V(BR)EBO
ton
tstg
tf
VCB=(–)40V, IE=0
VEB=(–)4V, IC=0
VCE=(–)2V, IC=(–)1A
VCE=(–)5V, IC=(–)1A
IC=(–)2.5A, IB=(–)0.125A
IC=(–)10mA, IE=0

IC=(–)1mA, RBE=∞

IE=(–)10mA, IC=0
See specified Test Circuit
See specified Test Circuit
See specified Test Circuit

* : The 2SA1469/2SC3746 are classified by 1A hFE as follows

70 Q 140 100 R 200 140 S 280
1 : Emitter
2 : Collector
3 : Base
JEDEC : TO-220ML
Ratings
(–)80
(–)60
(–)5
(–)5
(–)7
2
20
150
–55 to +150
Unit
V
V
V
A
A
W
W
˚C
˚C
Ratings
min typ max
(–)0.1
(–)0.1
70* 280*
100
(–)0.4
(–)80
(–)60
(–)5
0.1
0.5
0.1
Unit
mA
mA
MHz
V
V
V
V
µs
µs
µs
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquaters
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
71598HA (KT)/3277KI/N265KI No.1973-1/3
